- Low cost
- All stainless wetted parts
- Explosion proof enclosure (790)
- No O-ring or gland seals
- Isolates fluid from switch enclosure
- Hermetically sealed reed switch (770,780)
- SPDT and DPDT microswitches (790)
- CSA approved
- External gauge
- Class I Group C & D, Class II Group E, F & G
- Class III, Type 4x (790)
|
Perfect for:
- High-Low alarm systems
- Pump on, pump off level control systems!
- Overflow indication on vessels or tanks!
- Low Level Shut-Down on Tank Heating Processes!
|
- Size: 1",1 1/2", 2", 2 1/2", 3"
- Working pressure: 0-5000 PSI
- Temperature: 0-400 F
- Switches: reed switch (770,780), microswitch (790)
- Housing: 316SS
- Connections: NPT, flanged, 316SS
- External cage
- High temperature (400 F) switch
- High amp (11A) switch
- Gold contact switches
- Annulus plug
| |
***
