Babbitt RF Impedance

Point Level Control Systems

Strongest Warranty in the Industry

Babbitt level switches offer long-term reliability backed by the strongest warranty in the industry.

Point Level Switches

Point Level Switches are used to determine when a liquid or dry material has reached a predetermined level. Once the media reaches the level, a contact opens or closes and sends an output to an alarm, pump, PLC or other control device. These types of instruments are ideal when continuous measurement or monitoring of intermediate level is not important. Point level switches are typically used to control low or high levels in tanks, hoppers, silos or other vessels in order to improve efficiency and to prevent spills or overfill conditions. These units can also be used as secondary instrumentation to provide redundancy in the event that the primary instrument fails. Point Level Switches are also commonly referred to as a Point Level Sensor, Water Leak Sensor, Water Sensor Alarm, Liquid Level Switch, Liquid Level Sensor, Leak Detection Sensor, High Level Switch, Pump Control Switch, Silo Level Indicator and Bin Level Monitor.

Standard and custom units are available. To determine which instrument is right for your application, contact us for application assistance.

Typical Applications for Point Level Switches:

• High or low level alarm
• Overflow protection
• Leak detection
• Oil/Water interface
• Pump control

Liquid & Dry Materials:

• Water/Wastewater
• Acids/Caustics
• Chemicals/Oils
• Slurries
• Flour/Grains
• Powder/Plastics
• Sand/Cement

Babbitt LS2000 Series — RF Impedance Level Switch

The LS2000 is a low-cost, solid-state RF impedance point level switch designed for reliable level detection in both liquid and dry materials. With no moving parts to wear out or jam, the LS2000 significantly reduces maintenance and downtime. Proprietary RF technology ensures stable measurement while ignoring product buildup, eliminating the need for frequent recalibration.

• 10 Amp SPDT relay output
• Solid-state design — no moving parts
• Explosionproof / weatherproof housing
• Probe length can be modified in the field
• Rollock™ probes
• Screwdriver sensitivity adjustment
• Probe status lamp
• Adjustable time delay
• High/Low fail-safe (field adjustable)
• Easy-on probe connection

Application Performance Guarantee:
If within 60 days of purchase the LS2000 does not perform according to specifications in an approved application, it may be returned for full credit.
